Best selling stand alone control panel. Features 8 fully programmable zones & accepts up to 6 backlit remote keypads |
|
|
|
|
Slimline discreet stand alone control panel. Features 8 fully programmable zones & accepts up to 6 backlit remote keypads. Nominated Product of the Year 2000 by PSI magazine. |
|
|
|
|
|
|
|
|
|
|
Best selling control panels with remote keypad. Featuring 8 fully programmable zones & accept up to 6 backlit remote keypads. R8Plus includes EOL wiring, communicator interface & accepts Veritas Excel LCD keypads |
|
|
|
|
All the features of the Veritas R8 Plus including an LCD keypad for even easier programming & operation. |
|
|
|
|
Performance
TRIPLEX
Video in No. Of Channel 8
Signal Type NTSC, PAL
Signal Level 1.0Vpp Composite (+-10%) / 75Ohm Balanced
Audio in No of Channel 2
Signal Level Line in
Main display BNC Composite(NTSC/PAL)
VGA 1024X768 @60Hz
Live display speed 240CIF/sec, 200CIF/sec
BNC Signal Level 1.0Vpp Composite (+-10%) / 75Ohm Balanced
Screen Split 1/ 4/ 9/ ??
Sequence Editable sequence / Dwell time control
Spot display No. Of Channel 2
Quad spot(Advanced Digital Spot) No
Signal Level 1.0Vpp Composite (+-10%) / 75Ohm Balanced
Audio output
No of Channel 1
Signal Level Line out
Motion detection sensor resolution 16X16
Sensitivity 10 steps
Sensor In
No. Of input 8(1 Relay, 7 Open collector TR)
M:N mapping Yes
Digital Out No. Of relay 1
No. Of open collector 7
User Interface
GUI Yes(Alpha blending)
Control device Keypad/PTZ Control keyboard/ Remote controller
Recording Video CODEC MPEG-4
Resolution CIF(352X240, 352X288), 2CIF(704X240, 704X288), 4CIF(704X480, 704X576)
Max frame rate 120 CIF/sec, 100 CIF/sec |
|
Performance
TRIPLEX
Video in No. Of Channel 16
Signal Type NTSC, PAL
Signal Level 1.0Vpp Composite (+-10%) / 75Ohm Balanced
Audio in No of Channel 4
Signal Level Line in
Main display BNC Composite(NTSC/PAL)
VGA 1024X768 @60Hz
Live display speed 480CIF/sec, 400CIF/sec
BNC Signal Level 1.0Vpp Composite (+-10%) / 75Ohm Balanced
Screen Split 1/ 4/ 9/ 16/ ??
Sequence Editable sequence / Dwell time control
Spot display No. Of Channel 4
Quad spot(Advanced Digital Spot) No
Signal Level 1.0Vpp Composite (+-10%) / 75Ohm Balanced
Audio output
No of Channel 1
Signal Level Line out
Motion detection sensor resolution 16X16
Sensitivity 10 steps
Sensor In
No. Of input 16(1 Relay, 15 Open collector TR)
M:N mapping Yes
Digital Out No. Of relay 1
No. Of open collector 15
User Interface
GUI Yes(Alpha blending)
Control device Keypad/PTZ Control keyboard/ Remote controller
Recording Video CODEC MPEG-4
Resolution CIF(352X240, 352X288), 2CIF(704X240, 704X288), 4CIF(704X480, 704X576)
Max frame rate 120 CIF/sec, 100 CIF/sec
|
|
|
|
|
|
|
•Metal housing to avoid violence.
•5 LED indicators and 1 beeper for identification.
•Built-in anti-tamper function.
•TTL serial output for various application.
•Built-in watchdog to prevent the halting.
•WG port support for anti-pass-back.
•User capacity: 1,024, event logs: 1,200.
•2 sets of auto-open zone editing in stand-alone.
•3 control modes for selecting, M4, M6 and M8.
•3 access modes: card only, card or pin, card and pin.
•11 sets of time zone for various accessing.
•SOYAL software support for networking and time-attedance.
•Easily integrated with SOYAL or others access control system.
|
•Controller with built-in reader and door relay.
•Weatherproof and vandal-resistant for external installation.
•User friendly editing interface supported by LCD panel.
•TTL serial port for connecting external printer, LED ect.
•Built-in anti-tamper function.
•Built-in waterdog to prevent the system from locking up.
•An extra WG port which enables connection to another WG reader(for exit or anti-pass-back).
•Easily integrated with SOYAL or other access control system.
•Event log preserved for up to 10 years. |
|
|
|
|
|
|
|
|
|
|
|
New Piezo Technology
Over 500,000 operations from 4xAA cells
PVD, weather resistant, low maintenance finish
Connections for remote release by reception desk button
Connections for release by alarm system
Code free entry mechanically by key or electronically from keypad
Allows up to 90 user codes 4, 5 or 6 digits long
Tamper alarm and low battery warning
|
|
